Beskrivelse
Den nye thermion 2 er et super værktøj, til udenlandsjagt på vildsvin.
https://www.pulsar-nv.com/glo/products/33/thermal-imaging-riflescopes/thermion-version-2/
Main
Sensor
384×288 pix. @ 17 µm (NETD <40 mK)
Objective lens
F35/1.0
Magnification, x
2.5 – 10 (x4 zoom)
Field of view (HxV), degrees / m@100m
10.7×8.0 / 18.7×14.0
Detection range, m
1350
Sensor
Type
uncooled
Resolution, pixels
384×288
Pixel pitch, µm
17
NETD, mK
<40
Frame rate, Hz
50
Optics
Objective lens
F35/1.0
Magnification, x
2.5 – 10
Field of view (HxV), degrees / m @ 100 m
10.7×8.0 / 18.7×14.0
Eye relief, mm
50
Display
Type
AMOLED HD
Resolution, pixels
1024×768
Range Performance
Detection range, m
1350
Laser Rangefinder
Safety class for laser equipment according to IEC 60825-1:2014
–
Wavelength, nm
–
Max. measuring range, m
–
Measurement accuracy, m
–
Reticle
Click value, H/V, mm at 100 m
18 / 18 (от minimum magnification)
Click range, H/V, mm at 100 m
3600 / 3600
Number of preloaded reticles
10+
Video Recorder
Video / photo resolution, pixel
1024×768
Video / photo format
.mp4 / .jpg
Built-in memory, GB
16
Built-in memory capacity
–
Wi-Fi
Wireless Protocol
Wi-Fi
Wireless Standard
802,11 b/g
Frequency, GHz
2.4
Line-of-sight reception range, m
15
Environmental Characteristics
Degree of protection, IP code (IEC60529)
IPХ7 (waterproof)
Operating temperature range, °С
-25 – +50
Connections and Compatibilities
Max. recoil power on rifled weapon (Eo), Joules
6000
Shock resistance on the smooth-bore rifles, caliber
12
Mounting brackets on weapon
Standard 30 mm rings
Power Supply
Output voltage, V
3.0 – 4.2
Battery type
Dual Li-Ion B-Pack Mini Power System: 2 A·h Changeable Battery (external) / 3.2 A·h Battery (internal)
Capacity, mAh
2000 (external) + 3200 (internal)
Operating time on battery pack (at t=22°C), h *
5+
External power supply, V
5 (Micro USB Type B)
Weight & Size
Body material
Metal
Dimensions, mm
399x78x83
Weight, kg
0.9
