Beskrivelse
Det ny dag og natsigte fra Pulsar er af allerhøjeste kvalitet. med knivskape billeder i HD
Main
Sensor
CMOS 1928×1088
Magnification, x
3.5 – 14 (x4 zoom)
IR Illuminator wavelength, nm
IR not included
IR Optical power, mW
–
Detection range, m
500 (with IR 940 nm) / 550 (with IR 850 nm)
Sensor
Type
FHD CMOS
Resolution, pixels
1928×1088
Optics
Objective lens
F50/1.4
Magnification, x
3.5 – 14
Field of view (HxV), degrees / m @ 100 m
6.7×5 / 11.7×8.8
Eye relief, mm
50
Display
Type
AMOLED
Resolution, pixels
1024×768
Infrared Illuminator
Model
–
Emitter
–
IR wavelength, nm
–
IR Optical power, mW
–
IR spot position adjustment
–
Range Performance
Detection range, m
500 (with IR 940 nm ON) / 550 (with IR 850 nm ON)
Laser Rangefinder
Safety class for laser equipment according to IEC 60825-1:2014
–
Wavelength, nm
–
Max. measuring range, m
–
Measurement accuracy, m
–
Reticle
Click value, H/V, mm at 100 m
11 / 11
Click range, H/V, mm at 100 m
2200 / 2200
Number of preloaded reticles
10
Video Recorder
Video / photo resolution, pixel
1024×768
Video / photo format
.mp4 / .jpg
Built-in memory, GB
16
Wi-Fi
Wireless Protocol
Wi-Fi
Wireless Standard
802,11 b/g/n
Frequency, GHz
2.4GHz
Bluetooth
Wireless Protocol
BLE 4.2
Wireless Standard
IEEE 802.15.1
Frequency, GHz
2.4
Environmental Characteristics
Degree of protection, IP code (IEC60529)
IPХ7
Operating temperature range, °С
-25 – +50
Connections and Compatibilities
Max. recoil power on rifled weapon (Eo), Joules
6000
Shock resistance on the smooth-bore rifles, caliber
12
Mounting brackets on weapon
Standard 30 mm rings
Remote control
Pulsar BT (optional)
Supported Application
Stream Vision 2
Power Supply
Output voltage, V
3.0 – 4.2
Battery type
Dual Li-Ion B-Pack Mini Power System: 2 A·h Changeable Battery (external) / 4.9 A·h Battery (internal)
Capacity, mAh
2000 (external) + 4900 (internal)
Operating time on battery pack (at t=22°C), h *
10
External power supply, V
5 (USB Type C)
Weight & Size
Body material
Aluminum alloy
Dimensions, mm
408x78x83
Weight, kg
1.15
Trade Data
SKU (Model #)
76635
